Rahmen UD CARBON T800, TNT, ALLOY ROCKER AND SWINGARM, 120mm TRAVEL, DROPOUT FOR 148x12mm BOOST, 29"
Rahmengrössen 15", 17", 19", 21"
Gabel FOX 34 FLOAT RHYTHM 29", 15x110mm AXLE, TAPERED, GRIP, TRAVEL: 120mm, 2-POSITION SWEEP ADJUST
Dämpfer FOX FLOAT DPS PERFORMANCE, SV, EVOL, 3 POS, 190mm LENGTH, HARDWARE: 22.2mmx8mm
Vorbau LEVELNINE RACE, BARBORE: 31.8mm, 1 1/8", ANGLE:6°
Steuersatz FSA NO.42/48 ACB, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 7.8mm TOP COVER
Lenker LEVELNINE RACE RISER BAR 740mm, 9° ANGLE, 15mm RISE, 31.8mm
Schaltwerk SHIMANO XT RD-M8000 GS SHADOW PLUS DESIGN, TOP NORMAL, DIRECT MOUNT TYPE, 11-SPEED
Umwerfer SHIMANO XT FD-M8020D, DIRECT MOUNT, SIDE SWING
Schalthebel SHIMANO XT SL-M8000, DIRECT ATTACH TO BRAKE LEVER, ISPEC II
Bremsen SHIMANO XT BR-M8000, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180mm, R:180mm ROTORS, ICE TECH
Bremshebel SHIMANO XT BL-M8000, ISPEC II
Kurbelgarnitur SHIMANO XT FC-M8000-B2, BOOST, HOLLOWTECH II, 36-26 TEETH
Innenlager SHIMANO PRESSFIT MT500-PA
Sattelstütze KIND SHOCK LEV SI, 15": 100mm, 17" & 19": 125mm, 21": 150mm TRAVEL, REMOTE, 31.6mm
Sattel SELLE ITALIA X3 XP
Felgen ALEXRIMS MD-27, 32 HOLES, INNER WIDTH 27mm, 29"
Nabe vorne SHIMANO HB-M6010-B, 32 HOLES, 15x110mm BOOST THRU AXLE
Nabe hinten SHIMANO FH-M6010-B, 32 HOLES, 12x148mm BOOST THRU AXLE
Kette SHIMANO CN-HG601-11
Kassette SHIMANO CS-M7000, 11-42 THEETH, 11-SPEED
Reifen SCHWALBE NOBBY NIC ADDIX SPEEDGRIP, SNAKE SKIN, TL EASY 29x2.35"
Nettogewicht in kg 13.4
Gänge 22-SPEED
Einsatzbereich Crosscountry / Marathon, Tour / Trail
Federweg Gabel 120mm
Federweg Hinterbau 120mm
Rahmenmaterial CARBON
Laufradgrösse 29"
Rahmengeometrien FULLY
